Drum Rotary Mower

Quantity:
  • DM125, DM135, DM165
The Smart Inexpensive Disc Mower Alternative
FRED drum mowers are built to last. This kind of machine have been very popular in the world for some years. We have been building them using only top quality materials. The quality of our drum mowers is unmatched by any competitor.
These proven drum mowers became very popular through the years due to their literally unmatched sturdiness and extremely long lasting, trouble-free and maintenance-free operation.
Hundreds of thousands have been sold all around the world. Drum mowers in use for ten or twenty years are no exceptions. Because of their mechanical robustness, these mowers can mow even the heaviest types of grasses and forage crops. At the same time, they can be operated at higher speeds so their productivity is much higher than anyone would expect from a 6 feet wide mower.
As always with FRED MACHINERY, DM mowers represent more value for your money. In fact, their price-performance relation makes the drum mowers a class of its own.
The blade location on the outside of large diameter drums creates very high blade speed, efficiently cutting just about any type of grass or forage.
The drums are precisely balanced for a smooth, vibration-free run.
Tough, long lasting, easy-to-replace wear discs are freewheeling at the bottom of the mower drums. The carefully selected suspension spring reduces down pressure.
The drums are driven by a heavy duty gearbox equipped with quiet bevel gears. Simple gearbox design with a minimum number of moving parts is one of the features that make this mower virtually maintenance-free. The gearbox is filled with grease, rather than oil, eliminating any chances of leaks and allowing the mower to work on slopes. The high location of the gearbox also protects it from mechanical damage.
The metal hood resists abuse as well as heavy snow during winter storage. Metal rails around the safety curtain protect the most exposed areas of the curtain, extending its life considerably.
Switching from working to transport position is effortless. On models 165 and 185, just swing the mower back (no hydraulic outlets required on the tractor).
The breakaway safety system protects the mower when a drum hits an obstacle.
Semi-automatic belt tensioning cuts maintenance time
Blades are reversible and twisted for a high quality cut and increased safety. Blades are mounted on large diameter pins and retained by a proven quick-release system for quick change.



How does the drum mower work?


Working video on Youtube:

Model         DM125 DM135 DM165
Cutting Width(mm) 1250 1350 1650
Quantity of cutting disc 2 2 2
Working Efficiency(km/h) 15 15 15
Matched Power(HP) 20~45 35~50 45~60
Quantity of cutting knife 6 6 6
Cutting Knife size(mm) 100x47x3 100x47x3 100x47x3
Knife Material 65Mn 65Mn 65Mn
PTO Speed(r/min.) 540 540 540
Disc Speed(r/min.) 1620 1620 1620
Machine Size(mm)  2300x800x950  2400x800x1050 3000x900x1100
Weight(kg) 280 KGS 320 KGS 430 KGS


Pulley Belt                 Cutting Knife

           Transmission Belt                                             Cutting Knife
